1234 (D'MAK Power Control Center Panel (PCC)- D'MAK/2024/1234)

₹10,000.00

₹10,000.00
  • BOQDESCRIPTION: 400A 4P 40kA MCCB, Release: Microprocessor LSI Release, Type: P630; MAKE: HAGER; CATALOG NUMBER: HNW401JR; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Rotary Handle-Extended for MCCB Type: P630; MAKE: HAGER; CATALOG NUMBER: HXW031H; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Spreader Terminals 4P (Set of 4) for MCCB Type: P630; MAKE: HAGER; CATALOG NUMBER: HYD015H; QTY: 2; TOTAL QTY: 2
  • BOQDESCRIPTION: Auxiliary Contact for MCCB Type: P630; MAKE: HAGER; CATALOG NUMBER: HXA021H; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 400A 4P ATS, Open Execution; MAKE: DMAK; CATALOG NUMBER: DAT4P400; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 2; TOTAL QTY: 2
  • BOQDESCRIPTION: Yellow Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Blue Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Green Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Amber Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 400/5A 10VA Acc. Cl: 1 Tape Insulated Ring Type Current Transformer, ID: 30mm.; MAKE: P TECH; QTY: 3; TOTAL QTY: 3
  • BOQDESCRIPTION: Ammeter, 1Ph, Acc. CL: 1, Size: 96X96, Model: DMAK AM-91; MAKE: DMAK; CATALOG NUMBER: DMAK AM-91; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Voltmeter, 1Ph, Acc. CL: 1, Size: 96X96, Model: DMAK VM-91; MAKE: DMAK; CATALOG NUMBER: DMAK VM-91; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Multifunction Meter with RS485, LED Display, 3Ph, Parameter: VAF + Power + PF + Current/Power Demand + RPM + THD + Min-Max + Active/Reactive/Apparent Imp/ Exp/Forwarded, Active Net, Imp/exp Gross, Acc. CL: 1, Aux. Supply: 40-300V AC/DC, Size: 96x96, Model: Elite 103; MAKE: SECURE/DMAK; CATALOG NUMBER: Elite103; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 3P Ammeter Selector Switch, 4 Position Current in each phase with OFF, used with CT, 90Deg.; MAKE: KAYCEE; CATALOG NUMBER: N3R39AP; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 3P Voltmeter Selector Switch, 4 Position Voltage between phases with OFF, 90Deg.; MAKE: KAYCEE; CATALOG NUMBER: N2R39VP; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 1P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN106N; QTY: 6; TOTAL QTY: 6
  • BOQDESCRIPTION: 63A 4P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN463N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 12.5kA, 2P, Type 1 + 2 Surge Protection Device with Remote Signaling; MAKE: HAGER; CATALOG NUMBER: SPL212R; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 100A 4P 18kA MCCB, Release: TM Release(fixed overload, fixed short circuit) , Type: X160; MAKE: HAGER; CATALOG NUMBER: HDA101Z; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 125A 4P 18kA MCCB, Release: TM Release(fixed overload, fixed short circuit) , Type: X160; MAKE: HAGER; CATALOG NUMBER: HDA126Z; QTY: 2; TOTAL QTY: 2
  • BOQDESCRIPTION: 63A 4P 18kA MCCB, Release: TM Release(fixed overload, fixed short circuit) , Type: X160; MAKE: HAGER; CATALOG NUMBER: HDA064Z; QTY: 6; TOTAL QTY: 6
  • BOQDESCRIPTION: 63A 4P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN463N; QTY: 9; TOTAL QTY: 9
  • BOQDESCRIPTION: 40A 4P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN440N; QTY: 3; TOTAL QTY: 3
  • BOQDESCRIPTION: 25A 2P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN225N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: AC3: 25A 3P Power Contactor, Coil Voltage: 230V AC, Aux. contact: 1NO+1NC, Type: HWC-25; MAKE: HAGER; CATALOG NUMBER: EX002511D; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Electro-Mechanical Time Switch, Quartz 1 channel 1 daily dial 3 module, Contact Rating: 16A AC1; MAKE: HAGER; CATALOG NUMBER: EHN111; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 63A 4P 18kA MCCB, Release: TM Release(fixed overload, fixed short circuit) , Type: X160; MAKE: HAGER; CATALOG NUMBER: HDA064Z; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Yellow Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Blue Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 60/5A 5VA Acc. Cl: 5 Tape Insulated Ring Type Current Transformer, ID: 25mm.; MAKE: P TECH; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Ammeter, 1Ph, Acc. CL: 1, Size: 96X96, Model: DMAK AM-91; MAKE: DMAK; CATALOG NUMBER: DMAK AM-91; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Voltmeter, 1Ph, Acc. CL: 1, Size: 96X96, Model: DMAK VM-91; MAKE: DMAK; CATALOG NUMBER: DMAK VM-91; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Power Factor Meter, 3Ph - 3EL - 4W, Range : 1A/5A & 110V/230V/440V AC, Accuracy Class : (+)(-)2°, Size : 96x96, Model: AE 68302; MAKE: AE; CATALOG NUMBER: AE 68302; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 3P Ammeter Selector Switch, 4 Position Current in each phase with OFF, used with CT, 90Deg.; MAKE: KAYCEE; CATALOG NUMBER: N3R39AP; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 3P Voltmeter Selector Switch, 4 Position Voltage between phases with OFF, 90Deg.; MAKE: KAYCEE; CATALOG NUMBER: N2R39VP; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: FAN WITH AIR VENT; MAKE: REPUTED; QTY: 2; TOTAL QTY: 2
  • BOQDESCRIPTION: 6A 1P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN106N; QTY: 4; TOTAL QTY: 4
  • BOQDESCRIPTION: 40A 3P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN340N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 15kVAr 3Ph Normal Duty PhiCap-Cylindrical 440V AC Capacitor; MAKE: EPCOS; CATALOG NUMBER: B32344N4152A 40; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 16kVAr 3Ph Capacitor Duty Contactor, Voltage: 240V AC, Aux.Contacts: 1NO+1NC, Type: Standard series; MAKE: EPCOS; CATALOG NUMBER: B44066S1611C240; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Spring Return Metallic Push Button 22.5 mm; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Green Spring Return Metallic Push Button 22.5 mm; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 1NO Contact Block; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 1NC Contact Block; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 2-Position Metallic Selector Switch; MAKE: REPUTED; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 1P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN106N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 32A 3P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN332N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 10kVAr 3Ph Normal Duty PhiCap-Cylindrical 440V AC Capacitor; MAKE: EPCOS; CATALOG NUMBER: B32344N4102A 40; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 10kVAr 3Ph Capacitor Duty Contactor, Voltage: 240V AC, Aux.Contacts: 1NO+1NC, Type: Standard series; MAKE: EPCOS; CATALOG NUMBER: B44066S1011C240; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Spring Return Metallic Push Button 22.5 mm; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Green Spring Return Metallic Push Button 22.5 mm; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 1NO Contact Block; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 1NC Contact Block; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 2-Position Metallic Selector Switch; MAKE: REPUTED; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 1P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN106N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 16A 3P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN316N; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 5kVAr 3Ph Normal Duty PhiCap-Cylindrical 440V AC Capacitor; MAKE: EPCOS; CATALOG NUMBER: B32344N4052A 40; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 7kVAr 3Ph Capacitor Duty Contactor, Voltage: 240V AC, Aux.Contacts: 1NO+1NC, Type: Standard series; MAKE: EPCOS; CATALOG NUMBER: B44066S711C240; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Color LED Indicator 22.5 mm, Voltage: 220V AC; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Red Spring Return Metallic Push Button 22.5 mm; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: Green Spring Return Metallic Push Button 22.5 mm; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 1NO Contact Block; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 1NC Contact Block; MAKE: VALIYA; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 2-Position Metallic Selector Switch; MAKE: REPUTED; QTY: 1; TOTAL QTY: 1
  • BOQDESCRIPTION: 6A 1P 10kA C-Curve MCB; MAKE: HAGER; CATALOG NUMBER: NCN106N; QTY: 1; TOTAL QTY: 1
₹10,000.00
₹10,000.00

Inclusive of all taxes

Quantity

1 * (Pack of )

Total NaN items you will get in this order.

Per item price: ₹10,000.00
